Essential Tips to Select Fuel Storage Tanks for Gas Light Towers in the Australian Market

Fuel storage decisions on an Australian worksite are governed less by tank brochures than by how the fuel itself is classified. Petrol and diesel sit in different regulatory categories, create different hazardous areas, and therefore impose different separation, ventilation and electrical requirements on the same patch of ground. A site running gas light towers alongside diesel plant is managing two fuel classes at once. Getting the tank right means starting from that classification, then working outward to capacity, material and siting.
Key Takeaways
- Fuel class drives the tank rules, not tower type. Petrol is a Class 3 flammable liquid; diesel is treated as a combustible liquid under AS 1940 and as a hazardous chemical under WHS regulation. The storage requirements diverge from there.
- On-board tank capacity sets refuelling frequency; site storage sets refuelling autonomy. These are two separate calculations and both need answering before a tank is specified.
- Bunding and spill containment are compliance items, not upgrades. Self-bunded or double-walled tanks satisfy secondary containment expectations without a separate concrete bund.
- Material selection follows the environment, not the fuel alone. Steel and polyethylene both work; UV exposure, coastal salinity and transport method decide which.
- Hybrid gas-electric light towers cut refuelling trips. Where a site runs a battery bank with a small petrol generator as top-up, on-site fuel volume drops — which can move a site below the thresholds that trigger heavier storage obligations.
- Optraffic’s hybrid unit uses a 5KW gasoline generator paired with a battery bank, which is why its fuel planning profile differs from a conventional diesel plant of comparable output.
How AS 1940 Classifies Fuel for Gas and Diesel Light Towers
The first question is not tank size but which dangerous goods category the fuel falls into, because that single answer determines almost every downstream requirement.
Australian practice separates the two fuels by flash point. Diesel is treated as a flammable liquid category 4 under GHS, a band that overlaps with the C1 combustible liquid definition in AS 1940. Its use, storage and handling therefore falls under the Work Health and Safety Regulation as a hazardous chemical, confirmed by checking that the flash point on the safety data sheet sits above 60°C and at or below 93°C. Petrol sits below that threshold and is handled as a Class 3 flammable liquid.
| Attribute | Petrol (gas light towers) | Diesel (diesel light towers) |
|---|---|---|
| Dangerous goods treatment | Class 3 flammable liquid | Combustible liquid, C1 band |
| Flash point band | Below 60°C | Above 60°C, up to 93°C |
| Vapour behaviour at ambient temperature | Releases ignitable vapour readily | Requires heating or misting to ignite |
| Hazardous area created around the store | Larger; drives electrical equipment selection | Smaller, but still requires ignition source control |
| Governing storage standard | AS 1940 | AS 1940 |
The practical consequence is that a petrol store and a diesel store of identical volume are not equivalent installations. The petrol store generates the wider hazardous zone, which pulls in requirements around electrical fittings, ignition source exclusion and separation distances. Sites that run both fuels should treat them as two stores with two risk assessments, even when the tanks sit side by side.
Full requirements are set out in AS 1940:2017, the Australian Standard for the storage and handling of flammable and combustible liquids. Regulator guidance on how those classifications interact with WHS duties is published by WorkSafe Queensland.
Ignition source control at the tower itself follows the same logic as at the tank. Sites operating in atmospheres where vapour may be present should review how to prevent explosion risks around towable lighting units before finalising a fuel store location.
On-Board Tank Capacity Sets the Refuelling Interval
Site fuel storage only makes sense once the tower’s own tank capacity and burn rate are known, because those two numbers define how often someone has to walk to the tank.
The calculation runs in this order:
- Establish run hours per night. Continuous night shifts and dusk-to-dawn security lighting produce very different demand profiles.
- Establish consumption per hour at the load actually used. Towers rarely run all fixtures at full output for the entire shift.
- Divide on-board capacity by hourly consumption to get the refuelling interval in run hours.
- Multiply the interval shortfall across the fleet to size the site store. Ten towers refuelled every second night generate a very different logistics load than two.
Hourly consumption and on-board capacity vary by engine and by unit, so the figures should be taken from the specification of the machine on site. The relationship between tank size and run time is covered in more detail in the guide to fuel capacity of a light tower generator, and engine selection — which drives consumption at a given output — is covered in the guidance on choosing the right engine for a construction lighting unit.
Where a generator on the tower also feeds site equipment, consumption rises accordingly. That scenario is examined in the discussion of whether a light tower with generator can function as a site power source.
Selecting Fuel Storage Tanks for Light Towers: Capacity and Material
Capacity should be specified from refuelling autonomy — the number of days a site can operate without a fuel delivery — rather than from a round number that felt safe.
Three inputs decide the figure:
- Fleet daily draw, from the calculation above.
- Delivery lead time to the site, which on remote Australian projects can extend well beyond metropolitan norms.
- A reserve margin covering delivery delay, weather closure of access roads, and emergency operation.
Material selection then follows the site environment rather than the fuel:
| Tank material | Strengths | Watch points | Typical fit |
|---|---|---|---|
| Steel, self-bunded | High structural strength, integrated secondary containment, suits bulk volumes | External coating condition must be monitored in coastal and high-humidity zones | Long-duration civil, mining and infrastructure sites |
| Polyethylene | Light, corrosion-resistant, easy to relocate | Lower structural strength; UV-stabilised grades required for sustained exposure | Short-duration and access-restricted sites |
| Steel shell with polymer lining | Structural strength with an inert wetted surface | Higher cost; lining integrity requires inspection | Sites with aggressive ground conditions or extended tank life expectations |
Two selection rules apply regardless of material:
- Confirm compatibility with the exact fuel grade, including biofuel blends. Ethanol-blended petrol and biodiesel blends have different material compatibility profiles than straight fuels, and older tanks are not automatically suitable.
- Specify secondary containment as standard. Self-bunded and double-walled designs place containment inside the tank envelope, which removes the need to build and maintain a separate bund and simplifies relocation.
Siting and Installing Fuel Storage Tanks on Australian Worksites
Siting is where most compliance failures originate, because separation distances and hazardous area boundaries are decided before the tank arrives, not after.
The siting checklist:
- Set separation distances from buildings, boundaries, and protected places according to the tables in AS 1940 for the relevant fuel class and volume.
- Map the hazardous area created by the store and confirm that no fixed or portable electrical equipment inside that zone is unrated for the classification.
- Establish the tank on a stable, level base capable of carrying the full loaded weight without differential settlement.
- Plan the delivery vehicle path and the dispensing point so hoses do not cross traffic routes or pedestrian walkways.
- Position spill response equipment at the store, not in a distant site shed.
- Keep ignition sources — including running plant and vehicle movements — outside the classified zone.
Australian conditions add durability requirements that are easy to underestimate. Sustained UV exposure degrades unstabilised polymer; coastal salinity attacks coating defects on steel; and large diurnal temperature swings drive tank breathing, which affects vent sizing and water ingress. Tanks intended for multi-year deployment should be specified for these conditions from the outset rather than treated as a general-purpose item.
Remote deployment adds a further constraint: the tank has to reach the site. On linear and access-restricted projects the practical limit is often transport, not compliance, as the experience with portable lighting units on Australian rail projects illustrates.
Reducing Refuelling Demand: Hybrid Power for Gas Light Towers
The most effective way to simplify fuel storage is to need less fuel, and that is a power architecture decision rather than a tank decision.
Conventional diesel units burn fuel for every hour the lights are on. A hybrid architecture inverts that: the lighting runs from a battery bank, and the generator starts only to recharge. Fuel draw falls, refuelling trips fall, and total on-site fuel volume falls with them — which on smaller sites can keep the store below the volume thresholds that trigger the heavier end of AS 1940’s obligations.
Optraffic’s Hybrid Light Tower is built on this pattern, using a 5KW gasoline generator as the recharge source rather than a diesel engine. Two consequences follow for fuel planning:
- The fuel on site is petrol, not diesel, so the store is a Class 3 installation with the wider hazardous area — a point worth confirming with the site’s dangerous goods assessment before mobilisation.
- The volume required is smaller, because the generator runs only on recharge cycles rather than continuously through the shift.
The trade-off between fuel-burn architectures, including where diesel still makes sense, is examined in the comparison of solar hybrid and diesel lighting units for construction sites. For projects weighing fuel logistics against uptime across a mixed fleet, the broader light tower range covers diesel, hybrid and battery configurations, and deployment patterns across construction projects show how the choice usually falls out in practice.
FAQ: Fuel Storage Tanks for Light Towers in Australia
Does diesel need to be stored to AS 1940 if it is not a Class 3 dangerous good?
Yes. Diesel typically falls outside Class 3 because of its flash point, but it is still treated as a combustible liquid under AS 1940 and as a hazardous chemical under WHS regulation. Storage, handling and spill control obligations apply.
Is a separate bund required for a self-bunded tank?
Self-bunded and double-walled tanks provide secondary containment within the tank structure, which is the function a separate bund would otherwise serve. The design still has to be appropriate for the fuel class and volume, and the interstitial space should be monitored.
What tank material is best for coastal Australian sites?
Both steel and polyethylene are used successfully. Coated steel performs well provided the coating is inspected and maintained, since coating defects are where salinity attacks. UV-stabilised polyethylene avoids the corrosion question entirely but offers lower structural strength.
How much fuel storage does a light tower fleet need?
Size it from refuelling autonomy: fleet daily consumption, multiplied by the number of days the site must operate between deliveries, plus a reserve margin for delivery delay. Consumption should come from the specification of the units actually deployed.
Do gas and diesel light towers need separate fuel stores?
They should be assessed separately. Petrol creates a larger hazardous area than diesel at equivalent volume, so a shared store has to be designed to the stricter of the two classifications, and the separation and electrical requirements follow from that.
Conclusion
Fuel storage for light towers in the Australian market is a sequence, not a single purchase decision. Classify the fuel first, because petrol and diesel impose different obligations. Calculate refuelling interval from on-board capacity and actual consumption. Size site storage from delivery lead time and reserve margin. Then select material for the environment and site the tank to the separation and hazardous area rules in AS 1940. Sites that reduce fuel demand through hybrid power architecture arrive at a smaller, simpler store — which is often the cheapest compliance improvement available.
